413-13B Parking Aid - Vehicles With: Active Park Assist 2013 - 2014 Fusion
Removal and Installation Procedure revision date: 05/16/2013

Front Active Park Assist Sensors

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

    Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).
  1. Refer to: Jacking and Lifting - Overview (100-02 Jacking and Lifting, Description and Operation).

Installation

  1. To install, reverse the removal procedure.
  1. Carry out the azimuth system check.
    Refer to: Azimuth System Check (413-13B Parking Aid - Vehicles With: Active Park Assist, General Procedures).
