413-13B Parking Aid - Vehicles With: Active Park Assist 2013 - 2014 Fusion
General Procedures Procedure revision date: 08/1/2012

Azimuth System Check

  1. Turn the ignition ON, engine OFF.
  1. Set the parking brake on.
  1. Place the gearshift in DRIVE (D).
  1. Verify the parking aid system detects the specified object when placed within the 3 specified locations (P1, P2, P3) and record the distances.
  1. Confirm the recorded distances are within the specification ranges.
  1. If the active park assist system does not detect the object,
    Refer to: Parking Aid (413-13B Parking Aid - Vehicles With: Active Park Assist, Diagnosis and Testing).
