Steering Column Control Module (SCCM)

Removal

NOTE: Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

   Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).


1. If installing a new SCCM , connect the diagnostic scan tool and upload the module configuration information from the SCCM .


1. Refer to: Steering Wheel (211-04 Steering Column, Removal and Installation).


1. Refer to: Steering Column Shrouds (501-05 Interior Trim and Ornamentation, Removal and Installation).


1. Torque : 3 Nm

1. Torque : 3 Nm

Installation

1. To install, reverse the removal procedure.


1. If a new SCCM was installed, download the module configuration information from the diagnostic scan tool.
