211-04 Steering Column 2013 - 2014 Fusion
Removal and Installation Procedure revision date: 04/30/2013

Steering Column

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. Refer to: Steering Column Shrouds (501-05 Interior Trim and Ornamentation, Removal and Installation).
  1. Refer to: Steering Wheel (211-04 Steering Column, Removal and Installation).
  1. Torque : 25 Nm

  1. NOTE: The deployable steering column electrical connector retaining tabs are not easily accessible. Using an inspection mirror and needle-nose pliers may help in viewing and releasing the electrical connector retaining tabs.

  1. Torque : 25 Nm

Installation

  1. NOTE: Transfer parts as needed.

    To install, reverse the removal procedure.
