Wheel Bearing and Wheel Hub - Vehicles With: AWD

Removal

NOTICE: Suspension fasteners are critical parts that affect the performance of vital components and systems. Failure of these fasteners may result in major service expense. Use the same or equivalent parts if replacement is necessary. Do not use a replacement part of lesser quality or substitute design. Tighten fasteners as specified.

1. Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).


1. Discard the specified component. Follow local disposal regulations.


1. Special Tool(s) : 205-D070 (D93P-1175-B) Remover, Front Wheel Hub

1. Refer to: Brake Disc (206-04 Rear Disc Brake, Removal and Installation).


1. Discard the specified component. Follow local disposal regulations.


Installation

1. Torque : 133 Nm

1. Refer to: Brake Disc (206-04 Rear Disc Brake, Removal and Installation).


1. Torque : 200 Nm

1. Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).
