Rear Parking Aid Sensor

Removal

NOTE: Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

   Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).


1. Remove the rear bumper cover.
   Refer to: Rear Bumper Cover (501-19 Bumpers, Removal and Installation).


1. Disconnect the parking aid sensor harness from the rear bumper cover reinforcement.


Installation

1. To install, reverse the removal procedure.


1. Carry out the azimuth and elevation system checks.
   Refer to: Azimuth System Check (413-13A Parking Aid, General Procedures).
   Refer to: Elevation System Check (413-13A Parking Aid, General Procedures).
