Rear Bumper Cover

Removal

NOTE: Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

   Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).


1. Remove the rear wheel and tire assemblies.
   Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).


1. On each side.
   Torque : 1.5 Nm

1. Torque : 1.5 Nm

1. Remove the rear lamp assemblies.
   Refer to: Rear Lamp Assembly - Vehicles With: 4-Door (417-01 Exterior Lighting, Removal and Installation).


1. On each side.


1. On each side.


1. NOTE: On each side.

   Inspect the bumper reinforcements for damage to the bumper cover gripping surfaces.


1. If required.
   Torque : 1.5 Nm

Installation

1. To install, reverse the removal procedure.
