204-00 Suspension System - General Information	2013 - 2014 Fusion
General Procedures	Procedure revision date: 07/15/2013

Rear Toe Adjustment

NOTICE: Do not use any tools or equipment to move the wheel and tire assembly or suspension components while checking for relative movement. Suspension damage may occur. The use of tools or equipment will also create relative movement that may not exist when using hand force. Relative movement must be measured using hand force only.

Using alignment equipment and the manufacturer's instructions, check the rear toe setting on both sides.
General Equipment : Wheel Alignment System

Turn the component Counterclockwise (CCW) through 2 complete turns.
Torque : 175 Nm

NOTE: If equipped with Lane Departure Warning (LDW) System, camera alignment is required for the lane keeping alert and lane keeping aid to function correctly.
Connect the scan tool and perform the IPMA camera alignment procedure. Follow the scan tool directions.
