Battery Tray

Removal

1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

   Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).


1. Refer to: Battery (414-01 Battery, Mounting and Cables, Removal and Installation).


Vehicles without Auto-Start-Stop System

1. • Refer to: Air Cleaner (303-12A Intake Air Distribution and Filtering - 1.5L EcoBoost (118kW/160PS), Removal and Installation).

   • Refer to: Air Cleaner (303-12B Intake Air Distribution and Filtering - 1.6L EcoBoost (132kW/180PS) - Sigma, Removal and Installation).

   • Refer to: Air Cleaner (303-12C Intake Air Distribution and Filtering - 2.0L EcoBoost (184kW/250PS) - MI4, Removal and Installation).

   • Refer to: Air Cleaner (303-12D Intake Air Distribution and Filtering - 2.5L Duratec (125kW/170PS), Removal and Installation).


All vehicles

1. 1. 6X30 bolts
      Torque : 6 Nm
   2. 6X18 bolts
      Torque : 6 Nm

Installation

1. To install, reverse the removal procedure.
