Selector Lever Assembly

Removal

1. Apply the parking brake.


1. On both sides.


1. On both sides.


1. On both sides.


1. On both sides.


Installation

1. Torque : 9 Nm

1. On both sides.
   Torque : 8 Nm

1. Torque : 9 Nm

1. On both sides.
   Torque : 8 Nm

1. On both sides.


1. Torque : 7 Nm

1. Torque : 4 Nm

1. On both sides.


1. Release the parking brake.


1. NOTE: Anytime the parking brake switch electrical connector has been disconnected, the EPB system is deactivated and a DTC is stored in the ABS module. Perform the following step to restore the EPB system and clear the ABS module DTC .

   Apply and release the parking brake twice within 5 seconds, pausing with the switch in the NEUTRAL position for approximately one-half second between each apply and release.


1. Adjust the selector lever cable when a new selector lever is installed.
   Refer to: Selector Lever Cable Adjustment (307-05 Automatic Transmission External Controls, General Procedures).
