Brake Fluid Reservoir

Removal

NOTICE: Do not spill brake fluid on painted or plastic surfaces or damage to the surface may occur. If brake fluid is spilled onto a painted or plastic surface, immediately wash the surface with water.

NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Brake Master Cylinder (206-06 Hydraulic Brake Actuation, Removal and Installation).


1. Torque : 5.5 Nm

1. NOTE: Install new brake fluid reservoir seals. Lubricate the seals with clean, specified brake fluid.

   Material : Motorcraft® DOT 4 LV High Performance Motor Vehicle Brake Fluid / PM-20 (WSS-M6C65-A2) (ISO 4925 Class 6)

Installation

1. To install, reverse the removal procedure.


1. Refer to: Brake System Bleeding (206-00 Brake System - General Information, General Procedures).
