417-01 Exterior Lighting 2013 - 2014 Fusion
Removal and Installation Procedure revision date: 07/23/2013

High Mounted Stoplamp

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

    Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).
  1. Partially lower the headliner.

Installation

  1. NOTE: Clean adhesive tape from roof panel.

    To install, reverse the removal procedure.
