415-00C Information and Entertainment System - General Information - Vehicles With: AM/FM/CD/SYNC/Sony Audio System 2013 - 2014 Fusion
Removal and Installation Procedure revision date: 08/29/2012

Audio Digital Signal Processing (DSP) Module

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

    Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).

  1. NOTE: If installing a new module, it is necessary to upload the module configuration information to the scan tool prior to removing the module. This information must be downloaded into the new module after installation.

    Upload the audio DSP module configuration information to the scan tool by following the scan tool on-screen instructions.
  1. Torque : 7 Nm

Installation

  1. To install reverse the removal procedure.
  1. Download the audio module configuration information from the scan tool to the new audio DSP following the scan tool on-screen instructions.
