Front Strut and Spring Assembly

Removal

NOTICE: Suspension fasteners are critical parts that affect the performance of vital components and systems. Failure of these fasteners may result in major service expense. Use the same or equivalent parts if replacement is necessary. Do not use a replacement part of lesser quality or substitute design. Tighten fasteners as specified.

1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

   Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).


1. Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).


1. Refer to: Cowl Panel Grille (501-02 Front End Body Panels, Removal and Installation).


Installation

1. Torque : 35 Nm

1. Refer to: Cowl Panel Grille (501-02 Front End Body Panels, Removal and Installation).


1. Torque : 235 Nm

1. Torque : 115 Nm

1. Torque : 18 Nm

1. Refer to: Wheel and Tire (204-04A Wheels and Tires, Removal and Installation).


1. Refer to: Front Camber Adjustment - Vehicles Built From: 20-May-2013 (204-00 Suspension System - General Information, General Procedures).
