Cruise Control Module (CCM)

Removal

NOTE: Removal steps in this procedure may contain installation details.

1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

   Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).


1. Remove the front bumper cover.
   Refer to: Front Bumper Cover (501-19 Bumpers, Removal and Installation).


1. Remove the active grille shutters.


1. Torque : 27 Nm

1. Torque : 9 Nm

Installation

1. • To install, reverse the removal procedure.

   • Align the CCM .
