303-14B Electronic Engine Controls - 1.6L EcoBoost (132kW/180PS) - Sigma 2013 - 2014 Fusion
Removal and Installation Procedure revision date: 08/23/2012

Powertrain Control Module (PCM)

Removal

NOTE: Removal steps in this procedure may contain installation details.

  1. WARNING: Before beginning any service procedure in this section, refer to Safety Warnings in section 100-00 General Information. Failure to follow this instruction may result in serious personal injury.

    Refer to: Health and Safety Precautions (100-00 General Information, Description and Operation).

  1. NOTE: This step is only necessary when installing a new component.

    Download the module information to the diagnostic tool using the Programmable Modules Installation routine.
    General Equipment : Ford Diagnostic Equipment
  1. Torque : 10 Nm

Installation

  1. To install, reverse the removal procedure.

  1. NOTE: This step is only necessary when installing a new component.

    Upload the module information from the diagnostic tool using the Programmable Modules Installation routine.
    General Equipment : Ford Diagnostic Equipment
